HYAC Copper Communication Cable

Communication cable(HYAC)

• Steel Messenger
• Solid bare copper conductor
• PE insulation
• PET tape
• Aluminum-plastic bonded PE sheath

• Typical structural parameters:

  Type	Min. Thickness (mm)	Cable OD (Φmm)	WET (kg/km)	Type	Min. Thickness (mm)	Cable OD (Φmm)	WET (kg/km)
  5×2×0.4	1.4	21.5	200	5×2×0.6	1.4	23.0	230
  300×2×0.4	1.6	44.5	1290	200×2×0.6	1.8	50.5	1760
  5×2×0.5	1.4	22.5	220	10×2×0.7	1.6	26.0	310
  300×2×0.5	1.6	50.0	1820	100×2×0.7	1.8	44.5	1280

• Electrical Performance

  No	Project	Unit	Performance
  1	Conductor DC Resistance +20℃	W/km	ConductorOD mm 0.4 0.5 0.6 0.7 MAX 148.0 95.0 65.8 48.0
  2	Insulation Resistance +20℃ DC 100～500V	MW.km	≥10×103

  Environmental Performance

  No	Project	Unit	Performance
  1	Conductor Elongation	%	0.4mm:≥10 0.5mm:≥15 0.6,0.7mm≥20
  2	Insulation Tensile trength	MPa	≥16
  3	Insulation Elongation	%	≥300

  Others:

  Project	Content
  Application Scope	Used for transmitting analog signals of audio, 150kHz and below, and digital signals below 2048kbt/s and below. The working temperature of the cable is -30~+60℃, and the ambient temperature is not less than-5℃.

Product Tags:

PET tape copper communication cable



HYAC copper communication cable



Steel Messenger ccs cable



HYAC Copper Communication Cable Images
